Tried and True: Threading Eight Shafts

Threading four shafts is straightforward because the heddles fit perfectly between four fingers and a thumb. Threading eight shafts is tricky because we don’t have that many fingers! Thankfully, threading eight shafts can be as straightforward as threading four shafts. I like to think of it as four shafts in the back, and four shafts in the front.

For a review of threading four shafts, watch the short video in this post: You Can Prevent Threading Errors.

Threading Eight Shafts – Straight Draw

  • Set a small group of heddles apart on each shaft to prepare for threading the next group of ends.
  • Pick up the next threading group of ends and bring it to the front, on the left side of the separated heddles.
  • Lace the threading group of ends under, over, under, over the fingers of your left hand, palm up.
Threading eight shafts - the easy way.

Left hand becomes tensioning device for threading the heddles. I like to put my index finger in between the two parts of the cross, as separated by the lease sticks.

  • Wrap left hand index finger around the group of heddles on shaft one (the shaft nearest the back of the loom), the middle finger around heddles on shaft two, the ring finger around heddles on shaft three, the pinky around heddles on shaft four, and bring the thumb around to hold it all loosely together.
Threading eight shafts - the easy way.

Each warp end is taken in order from between the lease sticks, and then threaded through the heddles in order.

  • Thread the first four heddles—1, 2, 3, 4.
  • With the right hand, hold the group of warp ends taut, and open the fingers of the left hand to release the heddles.
  • Keeping the group of warp ends loosely laced around the fingers, slide the left hand toward you to thread the next four heddles—5, 6, 7, 8. Position your fingers around the heddles on each shaft, as you did for the first four shafts.
Threading eight shafts - the easy way.

Left hand slides toward the front of the loom to thread the next four heddles. It helps to hold the warp ends taut with the right hand while the left hand is repositioned.

  • After threading the second set of heddles, follow the same procedure as before and slide the left hand back again to thread 1, 2, 3, 4.
  • Continue sliding the left hand forward and back, until the threading is completed for that group of ends.
  • Check the threading group for accuracy, and then tie the group of ends together in a loose slip knot.
Threading eight shafts.

Always check for accuracy before moving on to the next threading group.

Complete the threading across the warp. And then, step back and admire the beauty of a beamed and threaded loom.

Glimakra Standard. Threading the loom.

Shafts are raised high for good access and visibility for threading, and for checking for accuracy.

Threading is complete. 8-shafts undulating twill.

Threading is complete. Cotton throw. 8/2 cotton, undulating (wavy) twill on eight shafts.

May you find efficient methods for the work of your hands.
