Cloth Beam Matters

Does it matter what happens at the cloth beam? Why not let the woven fabric go around the beam as is and forget about it? You have worked diligently at every stage to ensure an even warp. Now, preparing the cloth beam for cloth will ensure the warp remains even.

Warping slats are placed on the cloth beam.

Warping slats cover the cords and knots on the cloth beam so the handwoven fabric has a flat surface to lay against.

Warping slat over the tie-on bar prevents the tie-on threads from putting bulges in the fabric. Bulges can distort the fabric and put uneven tension on warp ends.

Warping slats around the cloth beam for a smooth start.

When the warping slats have covered one full revolution of the cloth beam, no more slats are needed. The twill pre-measured tape on the floor gives a clue to the extended length of this table runner on the loom.

The cloth beam holds obstacles that threaten the evenness of your warp. Any raised surface on the beam, like beam cords and tie-on knots, will distort the warp tension as the woven fabric wraps around it. Warping slats solve the problem. I lay in the slats around the beam, one by one, as I advance the warp. This forms a flat surface around which my freshly-woven fabric can hug as the cloth beam turns.

M's and O's long table runner. Linen weft.

Long M’s and O’s table runner on the loom. The sample piece and towel that preceded the table runner have already reached the cloth beam.

Fear makes obstacles for our path that disturb our peace and threaten our well-being. Trust in the Lord. Trust pushes fear aside. The day you are afraid–the moment you are afraid–put your trust in God. Know that the Lord is for you. Your trust in Him forms a firm layer to build your life on. Like the warping slats that are in place for your handwoven cloth, your trust in God is a foundation on which to roll the fabric of your life.

May you walk without fear.

Peace,
Karen

6 Comments

  • ellen santana says:

    whoa, never thought of that. i have been using paper on the warp beam and when i tried the slats they fell out of place when i loosened the warp at the end of a session. do you keep it taut always?es

    • Karen says:

      Hi Ellen, I do keep the warp under tension. I don’t see a need to completely loosen the warp at the end of a session. If I know I may not get back to it for a few days, I may loosen the warp a little, but there is always adequate tension on the warp for slats to stay in place. I have also left a warp under tight tension for days or weeks, and have never noticed an adverse effect.

      Also, when winding the warp, unless it is linen, I only put in slats every fourth round. So that means if some slats slip, it’s only a few on the outer layer.

      (I love my warping slats. I have found various uses for them, besides how they are “supposed” to be used.)

      Thanks for asking!
      Karen

  • Ruth says:

    Hi Karen,
    A couple of questions:
    Do you add slats on the cloth beam as your fabric is woven or just on the initial “round” to cover knots and such?
    Did your husband make your slats and what is the thickness of the slats you use?
    I love your sharing of knowledge! So many “little” things that make weaving more of a joy.
    Ruth

    • Karen says:

      Hi Ruth, Great questions!
      I add the slats just on the initial round. After that, the fabric just rolls onto itself.
      My husband did make some of my slats, but most of my slats were purchased from a Glimakra dealer. I think the slats are about 1/8″ thick.

      Yes, it is the little things that make a difference in the enjoyment and the quality of weaving.

      All the best,
      Karen

  • Linda Sloan says:

    What a wonderful message. Love your website.

Leave a Reply


Keep Threading Those Heddles

It will be worth it. 896 threads through these heddles, and then two ends per dent in the reed. This is the necessary dressing of the loom. I do it nine minutes, thirty-five minutes, and twenty-two minutes at a time. I do not accomplish it in one sitting. After accumulating almost five hours of threading, I’m ready to sley the reed.

Threading heddles.

Colored threads are 16/2 cotton, thicker than the 24/2 unbleached cotton threads.

Threading Heddles

Checking for threading errors before tying the group of ends into a loose slip knot.

It is easy to lose concentration when there are so many ends. The M’s and O’s threading has just enough variation in it to make me wonder if I did keep it all in the correct sequence. We will find out. The threading, correct or not, is always revealed as the fabric is woven.

Texsolv heddles of four shafts. Glimåkra Ideal.

Texsolv heddles on four shafts, threaded. Glimåkra Ideal.

Sley the reed. Glimåkra Ideal.

Two ends per dent are sleyed in this 22.5-dent-per-inch reed.

What is faith? Faith is putting your trust in something you have good reason to think is true. Stand firm, immovable, in your trust in the Lord. You put threads in the heddles because you have good reason to think these threads will become fabric. Don’t quit. Keep coming back to it. Be strong in faith. And do it from a framework of love. Your framework is always revealed in the cloth of your life.

May you stay strong.

Happy threading,
Karen

2 Comments

  • Anonymous says:

    Thank you for your encouragement on having faith. It was a very good start to my morning ☺️
    Anxious to see this project woven too. Your patience and fortitude for taking on difficult projects amazes me, a fellow weaver!
    Carolee

    • Karen says:

      Good morning, Carolee,
      Patience and fortitude are virtues, so thank you for that compliment. One reason I enjoy weaving so much is there are continual opportunities to stretch my knowledge and experience.

      Happy weaving,
      Karen

Leave a Reply


Tips for Taming String Yarn Weft Tails

Those pesky string yarn weft tails! There is a lot of starting and stopping with these mug rugs. Normally, tucking a weft tail back into the shed adds a bit of extra thickness at the selvedge. So, what about this very thick weft? It has the potential to throw everything off balance. A few easy tips help minimize the distortion the thicker weft can cause.

Taming String Yarn Weft Tails

  • Begin the thick weft on alternating sides. This will prevent one selvedge from building up more than the other.
  • Taper the end of the string yarn, cutting it at a steep angle.
  • Starting about 1 3/4″ inside the selvedge, send the shuttle through the shed toward the selvedge, going over or under the outermost warp end. Pull through until almost all of the weft tail is caught.
What to do with string yarn weft tails.

Starting the shuttle from the inside, going outward, is an easy way to catch all the separate threads of the string yarn.

Taming string yarn weft tails.

  • In same shed, send the shuttle back through to the other side, aware of encircling the one warp end.

Tucking in string yarn weft tails. Tips.

  • Beat. (Beat on open shed. Beat again. Change sheds. Beat again.)

How to manage string yarn weft tails.

  • Continue weaving.

Rep weave mug rugs. String yarn weft tails - tips!

  • To end the thick weft, leave a 1 3/4″ tail, and taper the end of the string yarn, as before. Lay the tail back in the last shed, going around the outermost warp end. Beat.

Things happen that throw us off balance. From personal celebrations to unexpected losses. Don’t be afraid. Putting trust in the Lord minimizes the inner turmoil. The Lord is my light. He lights my way. What is there to be afraid of? Wholehearted trust in the Lord pushes fearfulness away.

May you walk in a lighted path.

Happy weaving,
Karen

4 Comments

  • Liberty Stickney says:

    Hey Karen,
    Just wanted to say congratulations on another great project and article in the newest Handwoven Mag! I’m so proud of you! Thanks for all you hard work and help with our weaving!

    • Karen says:

      Hi Liberty, Thank you so much! It’s my joy to add my little two cents to the whole wide weaving world. My copy came in the mail yesterday! There are a lot of great projects in there.

      Thanks, friend,
      Karen

Leave a Reply


My Best Weaving Stunt to Date!

Do you ever go out on a limb? I’ve been known to play it safe. But not today! My excitement for weaving this kuvikas structure was severely dampened when I saw that the pattern in the cloth was not the pattern I intended. What happened? I had switched the threading for shafts 1 and 2! Consistently, too–all the way across the warp.

Start of kuvikas (summer and winter), and discovery of threading error.

While testing weft color options, I realize that this is NOT the pattern for which I thought I had threaded. Even though this pattern does reveal an “I” for “Isenhower,” I had my heart set on a square within a square.

I could leave the threading as is. No one would know. Oh, the arguments I had with myself at this point. “Take it out, and re-thread.” “You’d be crazy to take it out and re-thread.” The crazy self won. (I did find myself asking, “What solution would Becky Ashenden, the weaving solution genius, come up with?”) Here is the stupendous thing: I was able to correct the pattern by doing shaft-bar gymnastics. And no re-threading! What?! (I documented the process and will bring it to you in my Quiet Friday post at the end of the month.)

Kuvikas (summer and winter), cotton tabby and tencel pattern weft.

The sight of these little squares within squares makes me extraordinarily happy! 8/2 cotton tabby weft. Doubled 8/2 Tencel pattern weft. Kuvikas, as this weaver intended it to be.

There are times when we are called to go out on a limb. It’s the right thing to do. But the prospect is overwhelming. We ask, “Who? Me?” And “How, Lord?” Trust the Lord, one step at a time. He will be with you. Marvelous things will happen, catching even you by surprise.

May you know when to go out on a limb.

Happy,
Karen

4 Comments

  • Debbie Moyes says:

    Good for you! I bet you did debate long and hard but the square within a square looks wonderful! The other pattern is a bit awkward, as well and not being what you wanted.
    Whether to fix a mistake or something that doesn’t look right does come up often with all of us. I am usually in favor of changing it….
    Last night I was trying to do decreases in a knitting project and I kept having to rip it out as I wasn’t getting the pattern right…but it’s done now!
    What are you making?

    • Karen says:

      Debbie, Yes, this is a common dilemma for makers, because mistakes happen. Whether to ignore it and move on, or to find a fix. It depends on the degree of the error and the risk involved in the correction. This seemed like a big risk, but I thought it through long and hard before taking the leap. I needed to fix this to be able to enjoy the rest of the weaving.

      Right now, I am calling this “yardage,” which is code for “I don’t know what I will make from it.” Perhaps pillows, or a bag of some sort. I do need a bag for my laptop…

      All the best,
      Karen

  • Nanette Mosher says:

    But if you look at the sample, and imagine that you treadled each section the same length, wouldn’t you have a rather nice alternating square within a cress pattern? Considering the error, I’m surprised you got any good pattern! But yes, I always feel better taking out anything I’m not happy with! N.

    • Karen says:

      Hi Nanette, You’re right, it would have been an alternating square within a cross pattern, and it would have been a pleasant pattern. My husband liked it and would have been happy if I had woven it as is. But I wasn’t going to be satisfied with it. I do feel better now. 🙂

      Happy weaving,
      Karen

Leave a Reply


Kuvikas and Taqueté

Kuvikas and taqueté. There are always new things to try. I’m back to eight shafts. This Glimåkra loom is highly adaptable. It is no problem to set up the loom for a new project. You may have guessed that I like to switch it up. Four shafts or eight shafts, two treadles or ten. And, change the tie-up, too. I don’t mind. With this project, I am going to change the treadle tie-up again at the midway point, switching from kuvikas to taqueté.

Threading eight shafts on my Glimakra Standard loom.

Threading eight shafts. Four pairs of shaft bars have been added to switch from a four-shaft project to an eight-shaft project. Four additional upper lamms and lower lamms have also been added to the loom.

If you know and practice the basics, it’s not frightening to try new weave structures. Every new experience builds on what I’ve learned before. I can trust the system of weaving that I’ve been taught, and that I practice with every project. It makes sense.

Aquamarine cotton. Threading my Glimakra Standard loom.

After the warp is beamed, the warp ends are tied with an overhand knot into groups, according to the threading pattern. In this case, 48 ends are in each group. Counting the ends into groups helps eliminate, or at least reduce, threading errors.

Threading eight shafts for kuvikas and taqueté.

Complex, but not complicated. Warp ends are inserted into specific heddles to set up the loom for a particular type of cloth. Very systematic.

Don’t be afraid. The Lord not only teaches us his ways–his system, but offers us his strength while we learn. I can trust him for that. Trust replaces fear. I don’t have to find my own way, or guess. The system works. It makes sense. I learn to weave, and live, one step at a time, with freedom to enjoy the process.

May you rise above your fears.

All the best,
Karen

8 Comments

  • Shirley says:

    Hi Karen, I just love the colour. Can`t wait to see what it becomes. Have fun with it.

    • Karen says:

      Hi Shirley, I had this color left from another project where I used it for narrow stripes. I wasn’t sure how I would like it all by itself. So far, I’m loving it. I can hardly wait to cross it with weft!

      Thanks,
      Karen

  • Hi Karen,
    My Glimakra has four shafts right now. I wonder how hard it would be to buy the wood pieces the right thickness and cut them to the right sizes to add four more. I have a drill press for making the holes. I just warped mine with linen for a transparency. It’s the first time I’ve done it on this loom with the trapeze. I did 10″ bouts (3) of linen, but discovered that was a bit wide for linen. With linen, I think I’ll make my bouts 4-5″ max. next time, and then the tension will be better. Just wondering if you have experienced that with linen?

    • Karen says:

      Hi Lynette, I’m going to send you an email to tell you specifics on how my husband made additional shafts for my Glimakra Ideal loom.

      I had that exact issue with my linen bouts when I warped for the transparency. It ended up not affecting the warp tension overall – at least, I never noticed a problem while weaving. But I thought about doing smaller bouts next time. My usual rule of thumb is to stay around or under 200 threads or 10″.

      Happy weaving,
      Karen

  • JANET PELL says:

    Dear Karen, Thank you for your blogs, I am so in awe of your bravery for ‘going forth’, I love the color of your warp and cannot wait to see your project. How I wish I had your knowledge and experience. But your encouragement to everyone is a blessing for me. Maybe one day I will face the elements, be brave, and change from tabby to something as exciting as your projects.

    • Karen says:

      Hi Janet, You are so sweet! Everything is a step at a time. You will be ready for a brave step in weaving before you know it. Practice and enjoy what you know! There’s nothing wrong with tabby. It’s the basis for everything else at the loom.

      Happy Weaving,
      Karen

  • Cornelia says:

    Hi Karen,

    I would like to increase the size of the things i’m making. Therefor the question if it is possible to add 4 more additional shafts to my Glimakra counterbalance loom on which I currently have 4 shafts. Could it also be possible that you send the specifics on how to make additional shafts? I would really appreciate that!

    • Karen says:

      Hi Cornelia, Probably the best way to add shafts is to get them from a Glimakra dealer. Besides shafts, you will also need additional lamms, and possibly more treadles. My husband has made all these things for my smaller loom, but it was a very ambitious project, and his advice for others is to purchase the parts from a dealer, if possible.

      All the best,
      Karen

Leave a Reply
