Woven Transparency Cactus

I found a subject for my next transparency. It’s a prickly pear cactus in Texas hill country. Weaving this cactus is a fantastic experience! I started with a photograph, from which I made a cartoon. And I have an outline that shows where to place each color. It’s all based on the timeless beauty of colors in nature. I’m hopeful that when light shines through the final woven transparency we will see a likeness of the original cactus.

Prickly Pear Cactus in Texas hill country.

Prickly Pear Cactus in the front yard of our Texas hill country home.

Make a Cartoon

  • Crop and enlarge the photo. (I use Acrobat Reader to enlarge and print in multiple pages, and then tape the pages together.)

Prickly Pear Cactus in Texas hill country.

  • Outline the main lines of the picture.
  • Turn the enlarged picture over and draw the traced lines on the back to have the reverse image. (This transparency is woven from the back.)

Photo to sketch to cartoon for woven transparency.

  • Trace the line drawing onto a piece of buckram to use as the cartoon.
  • Draw a vertical dashed line down the center of the buckram cartoon.
  • Pin the cartoon under the weaving, lining up the center line on the cartoon with the center warp end. Move the pins, one at a time, before advancing the warp each time.

Buckram used for transparency cartoon.

Color Selection

  • Use the photograph to select yarn colors for the transparency. (I used the iPad to view the photo, and selected sixteen shades of 20/2 Mora wool.)
  • Sort the yarn by hues. (I used my iPhone camera black-and-white setting to help in the sorting.) Sorting by hues helps me blend similar-hued colors, and shows me the contrasts that will help define the picture.

Color selection for woven transparency. Sorting by hues.



Sorting colors by hues for woven transparency.

  • Assign a number to each yarn color.
  • Make the enlarged outline into a color-by-number sheet by designating a color or blend of colors for each section. (I taped this sheet to the wall beside my loom, to use as a color guide. The iPad photo also serves as a reference.)

Butterflies of Mora wool for woven transparency.

Virtues are timeless. Virtues are like colors that blend together to weave a masterpiece. When we let the Grand Weaver lay in the weft, these are the colors that appear as light shines through His woven transparency: love, joy, peace, patience, kindness, goodness, faithfulness, gentleness, self-control. And when this occurs, it shows that we are made in His image.

Making a transparency cartoon. Tutorial.



Woven transparency from a photo. How to.

May the next leg of your journey be a fantastic experience.

I’ll meet you back here on Tuesday, August 1st, 2017.
In the meantime, I hope you investigate claims of Jesus. Take time with people. Keep weaving. And the same for me.

Head over to Instagram to stay in touch with my daily journey.

Love,
Karen

16 Comments

  • Beth Mullins says:

    This is going to be fabulous!

  • So exciting to see your transparency! That is my absolute favorite thing to weave, and yours is inspiring me to do another one too. What size linen and sett are you using?

    • Karen says:

      Hi Lynette, You are responsible for inspiring me! I couldn’t stop thinking about your beautiful transparencies, and knew I wanted to make another attempt. It’s not hard for me to understand why this is your very favorite thing to weave. I may be following you in that! I can’t thank you enough for answering my questions behind the scenes!

      This is 16/2 linen, 12 epi.

      Happy Weaving,
      Karen

  • D'Anne Craft says:

    You’ve put lots of planning time into this piece. Can’t wait to see the finished work!

    • Karen says:

      Hi D’Anne, The planning for this has been a lot of fun. I was getting discouraged trying to find a good subject to weave, but when I found this pic that I took on our own property I got pretty excited about the whole thing! I can’t wait to show it to you when it’s finished!

      Karen

  • Liberty Stickney says:

    This is so exciting Karen, I can’t wait to see it!! Have a wonderful vacation, I will be looking forward to august and this finished piece!
    Liberty

  • Wende says:

    Love this!

  • Maria says:

    Karen,
    Where in the hill country do you live? I so enjoy your blog- I like how you “weave” your faith in your posts!! Gifted weaver and writer?

    • Karen says:

      Maria, We are a little north of Kerrville. We currently live in the Houston area, but this special place in Kerrville will become our permanent home when my husband retires. Your sweet thoughts are very touching. Let me know when you will be in Houston again, or in hill country. I’d love to meet up.

      Happy weaving,
      Karen

  • Carol Ashworth says:

    I am so glad I found your site! I love everything and have a lot to learn!
    I love how you try to do every so nice and neat!
    Carol

  • Patricia Tiemann says:

    Great blog! Thanks for posting so much info.

Leave a Reply


Tools Day: Umbrella Swift

The umbrella swift earns the “Cool Tool” award! I have sixteen skeins of 20/2 Mora wool (as seen in Skeins of Colors). Before making them into little butterflies of color for a woven transparency, I am winding the skeins into balls. This means I get to use one of my favorite tools–the umbrella swift. My GlimĂ„kra swift is simple to use and gives flawless results every time.

How to Use an Umbrella Swift

  • Attach the clamp of the umbrella swift to the side of the loom, or other secure structure, like a table. The swift functions vertically or horizontally. I prefer to position the swift horizontally so the yarn rolls off vertically. Also, I find it easier to hang the yarn on a horizontal swift than to place the yarn on a vertical swift, holding the yarn while expanding the umbrella.

How to use an umbrella swift. Tutorial.

  • Position the yarn ball winder so that it is in line with the umbrella swift, a short distance away. I clamp the yarn ball winder to my loom bench, and sit on a small stool behind the bench.

Yarn ball winder in use with umbrella swift.

  • Remove the yarn skein’s label and put it aside. Carefully unfold and untwist the skein of yarn and open it out to a big circle. Place both arms through the center of the circle of yarn and snap your arms outward. Repeat the snapping action one or two more times, with the yarn repositioned about a quarter turn each time. This helps straighten out the yarn for placing it on the swift.
  • Lower the “umbrella” of the swift by loosing the screw and pulling the bottom screw-piece toward the clamp. Place the opened and prepared skein of yarn around the swift.

Placing the skein on an umbrella swift. How to.

  • Push open the “umbrella.” Spread it open just far enough to hold the yarn taut. Tighten the screw to keep the swift in that position.

How to use an umbrella swift for weaving yarn.

  • Find the place(s) on the skein where the skein has been tied, and untie the knot(s). Identify the end of the yarn that is on the outer side of the skein and connect that end to the yarn ball winder. For consistency among multiple skeins of yarn, I have the umbrella swift turn in the same direction for each one, with the yarn unwinding from the top of the swift.

Putting skein of yarn on umbrella swift.

  • Turn the yarn ball winder until all the yarn has been unwound from the swift.

Set up for using umbrella swift. Tips.

Winding ball of yarn from umbrella swift.

Winding ball of yarn from umbrella swift.

  • Remove the yarn ball from the yarn ball winder and wrap the skein’s label on the new yarn ball.

New ball of yarn thanks to umbrella swift.

  • Collect the new balls of yarn and play with the colors in your imagination.

Mora wool. Getting ready for woven transparency!

May you take pleasure in your work of preparation.

All the best,
Karen

11 Comments

  • Dear Karen,
    Good morning, I just had the luck of stumbling onto your lovely blog and I see you have accomplished what I am struggling with. I too have a glimakra and I recently “upgraded” it to 8 shafts. Very long story short, I don’t have any documentation and I suspect the reason I’m getting terrible sheds is because of cord lengths. Is there any chance we could talk for a few minutes?
    On a pretty morning by the Bay,
    Astrig

  • Betsy says:

    Well, duh! I’ve never thought to use my swift horizontally! I’ll have to give it a try. It’s a little smaller than yours, but hopefully it will fit on the Standard upright.

    • Karen says:

      Hi Betsy, I hope it works for you! Horizontal seems logical to me, but I suppose if you think of it as an actual umbrella, it naturally would go in the vertical direction. The good thing is, it works either way!

      Karen

  • Thank you Karen for the explanation of use and excellent photos to accompany. I’d be lost without my swift. As we all know, skeins can bite you if you don’t treat them with respect!
    Alison

  • Ruth says:

    Rock Chalk, Jayhawk, KU. Love the KU foot stool(?)!
    Wonderful horizontal use of your skein winder. Never looked at using mine horizontally – must remember to keep an open mind and look at all possibilities in life.
    Happy weekend.

    • Ruth says:

      Guess I’m tired this morning. I intended to refer to the swift as a swift. LOL

    • Karen says:

      Hi Ruth, You took the bait. I was hoping to draw out any KU alumns with that little stool. 😉
      Good point about seeing possibilities. We can do surprising things if we are not set in our ways.

      All the best,
      Karen

  • tsw says:

    Karen, your photos and step by step instructions are clear and wonderful. As a former private investigator, I give you high marks for your ” evidentiary photography.” I am a wannabe weaver, awaiting retirement to spread my wings, attend Vavstuga, and weave away my retirement. In the meantime, I study, and gain inspiration and food for thought from your blog and the online weaving forums.
    If you only knew how much you nurture other people’s hearts and minds…
    You are a blessing to all of us!

    • Karen says:

      Dear tsw, I am touched by your thoughtful remarks. Your encouragement means so much to me!

      What a wonderful way to prepare for retirement! Keep dreaming, and seeing those dreams come to life. You have nurtured me today with your kindness.

      Happy weaving dreams,
      Karen

Leave a Reply


Tools Day: Double-Bobbin Shuttle

The first time I wove fabric that required a doubled weft I did not use a double-bobbin shuttle. I didn’t own one. I used a regular boat shuttle and sent it across twice, going around the outer warp end. Those first thick and thin towels came out beautifully. So I know it can be done.

Weaving with a double-bobbin shuttle. Tips.

Square pattern peeks through from below. Double-bobbin shuttle carries the doubled tencel weft for this kuvikas fabric.

The first time I used a double-bobbin shuttle I wondered if it was worth it. It was awkward and clumsy in my hands. Since that rocky introduction a few years ago, I have woven many meters with my double-bobbin shuttles. They have become cherished tools and efficient accomplices to some of my favorite fabric-making endeavors!

Tips for Weaving with a Double-Bobbin Shuttle (and a short video demonstration)

  • Practice. Make sure you allow extra warp length for practicing. You will probably need it at first. Have fun and laugh, and refrain from throwing the shuttle across the room.
  • Winding Equal Bobbins. Wind the first quill. Lay it close to the bobbin winder where you can see it easily. As you wind the second quill, attempt to match it in size to the first one. (Winding two quills with equal amounts of thread is no small challenge.)
Winding equal quills for a double-bobbin shuttle.

Visibility of the first wound quill is key for judging how much thread to wind on the second quill.

Winding quills for double bobbin shuttles.

Knowing when to stop is the trick. The ideal is for both quills to become empty at the same time. This only happens in your dreams. But sometimes you can get pretty close.

  • Sending the Shuttle. Sending the double-bobbin shuttle through the shed is the same as sending a regular boat shuttle across. The best release is done with a flick of the forefinger so the shuttle speeds across. Then, the doubled weft naturally snugs the selvedge, and the two threads are neatly aligned across the shed. With a slower, more timid shuttle send-off, the quills unwind unequally.
Weaving with a double-bobbin shuttle.

Holding the shuttle palm up, the forefinger launches the shuttle to glide quickly through the shed.

Results of timid shuttle send-off.

Timid or sluggish shuttle send-off lays unequal lengths of threads in the shed.

How to tips for weaving with a double-bobbin shuttle.

Deliberate send-off of the shuttle helps the threads to lay across the shed in equal lengths.

  • Receiving the Shuttle. Receiving the shuttle can be the awkward and clumsy part at first. Especially if you are trying to practice a quicker send-off. I catch the shuttle as for any boat shuttle, palm up. And then, if needed, I fold my two bottom fingers around the threads, guiding them to fall equally across the shed.
Using a double-bobbin shuttle. Tips.

After catching the shuttle, I gently close my fingers around the two threads, as needed, to guide them to fall evenly across the warp.

  • Weave. Enjoy the process.
Shuttle shadows. Karen Isenhower

Shuttle shadows.

May your practice produce perfection. (Well, maybe not perfection, but at least improvement.)

Happy weaving,
Karen

2 Comments

  • Debbie Moyes says:

    I have a stupid question. Why do you need to weave with two threads? Why not use one larger one?

    • Karen says:

      Hi Debbie, That’s a very smart question! It seems like it would make sense to weave with a larger thread instead of two thinner ones. Certainly easier. But two thinner threads have a way of laying better than one thicker thread, and fill the space better. Many drafts with a ground weave and pattern use a doubled weft for the pattern. Part of the difference is seen in wet finishing, too. The combined threads blossom out more than a single thread would.

      Thanks for asking!
      Karen

Leave a Reply


Tips for Taming String Yarn Weft Tails

Those pesky string yarn weft tails! There is a lot of starting and stopping with these mug rugs. Normally, tucking a weft tail back into the shed adds a bit of extra thickness at the selvedge. So, what about this very thick weft? It has the potential to throw everything off balance. A few easy tips help minimize the distortion the thicker weft can cause.

Taming String Yarn Weft Tails

  • Begin the thick weft on alternating sides. This will prevent one selvedge from building up more than the other.
  • Taper the end of the string yarn, cutting it at a steep angle.
  • Starting about 1 3/4″ inside the selvedge, send the shuttle through the shed toward the selvedge, going over or under the outermost warp end. Pull through until almost all of the weft tail is caught.
What to do with string yarn weft tails.

Starting the shuttle from the inside, going outward, is an easy way to catch all the separate threads of the string yarn.

Taming string yarn weft tails.

  • In same shed, send the shuttle back through to the other side, aware of encircling the one warp end.

Tucking in string yarn weft tails. Tips.

  • Beat. (Beat on open shed. Beat again. Change sheds. Beat again.)

How to manage string yarn weft tails.

  • Continue weaving.

Rep weave mug rugs. String yarn weft tails - tips!

  • To end the thick weft, leave a 1 3/4″ tail, and taper the end of the string yarn, as before. Lay the tail back in the last shed, going around the outermost warp end. Beat.

Things happen that throw us off balance. From personal celebrations to unexpected losses. Don’t be afraid. Putting trust in the Lord minimizes the inner turmoil. The Lord is my light. He lights my way. What is there to be afraid of? Wholehearted trust in the Lord pushes fearfulness away.

May you walk in a lighted path.

Happy weaving,
Karen

4 Comments

  • Liberty Stickney says:

    Hey Karen,
    Just wanted to say congratulations on another great project and article in the newest Handwoven Mag! I’m so proud of you! Thanks for all you hard work and help with our weaving!

    • Karen says:

      Hi Liberty, Thank you so much! It’s my joy to add my little two cents to the whole wide weaving world. My copy came in the mail yesterday! There are a lot of great projects in there.

      Thanks, friend,
      Karen

Leave a Reply


Tools Day: Swedish Weaving Draft

Cooks have recipes, builders have blueprints, and handweavers have weaving drafts. There are a few different formats, but all drafts carry the same essential information. There is the tie-up box, the threading pattern, and the treadling sequence. Finally, there’s the drawdown, a graphic representation of how all the threads intersect.

The two formats I see most often are the typical American draft (e.g., Handwoven), and the Swedish draft (e.g., VÄV Magasinet). Many American drafts assume jack looms; whereas, Swedish drafts usually assume counterbalance or countermarch looms. However, any loom can weave from any draft.

As Madelyn van der Hoogt says in The Complete Book of Drafting, “Any tie-up can be used for any type of loom. Discover from the tie-up which shafts must be up and which down for each shed, and do to the loom whatever is required to get them there.”

All the draft formats have this in common: The tie-up box is the starting point. The threading pattern and treadling sequence begin at that point, and go out from there.

The Swedish draft makes perfect sense (remember, of course, I weave on Swedish countermarch looms). I picture the draft as if it is lying flat in front of me.

Becky Ashenden says in the forward to Weave Structures the Swedish Way, “With this orientation of tie-up, treadling, and threading, the draft has a direct relationship to the weaving of the fabric. The tie-up’s location in the lower right-hand corner of the draft allows all other information to match as closely as possible the physical aspects of the loom.”

Here is a comparison of the Swedish and American draft formats:

Swedish Draft

Reading a Swedish draft.

Swedish draft, with a weft drawdown.

  • Weft drawdown (filled-in squares show lowered warp threads, weft passing over)
  • Tie-up is in lower right corner, and uses black squares to designate shafts that sink / white squares for shafts that rise
  • Threading is below the drawdown
  • Shafts are numbered from back of the loom to front, with the first shaft the furthest from the weaver seated at the loom
  • Treadling sequence is on the right, and reads from bottom to top
  • Treadles are numbered from right to left
  • For a “sinking shed” loom (countermarch or counterbalance loom), use the black squares to tie up sinking shafts
  • For a “rising shed loom” (jack loom), use the white squares to tie up rising shafts

American Draft

Reading weaving drafts.

American draft, with a warp drawdown.

  • Warp drawdown (filled-in squares show raised warp threads, weft passing under)
  • Tie-up is in upper right corner, and uses numerals to designate shafts that rise / white squares for shafts that sink
  • Threading is above the drawdown
  • Shafts are numbered from front of loom to the back, with the first shaft the closest to the weaver seated at the loom
  • Treadling sequence is on the right, and reads from top to bottom
  • Treadles are numbered from left to right
  • For a “sinking shed” loom (countermarch or counterbalance loom), use the white squares to tie up sinking shafts
  • For a “rising shed loom” (jack loom), use the squares with numerals to tie up rising shafts

Similarities between Swedish and American Drafts

  • Threading reads right to left
  • Squares in the tie-up box represent treadle cords that attach treadles to corresponding shafts
Weaving draft in place for weaving mug rugs.

Draft is hanging at the corner of the loom. The fabric logically grows in the same direction as the sequence of weft picks as seen on the treadling draft.

Resources
Getzmann, Ulla, and Becky Ashenden. Weave Structures the Swedish Way. Shelburne, MA: Väv Stuga Press, 2006.
Hoogt, Madelyn Van der. The Complete Book of Drafting for Handweavers. Coupeville, WA: Shuttle-Craft Books, 1993.

May you flourish at your loom.

All the best,
Karen

14 Comments

  • Julia says:

    Hi Karen,
    Thank you for this comparison of the two ways to write drafts, this will make translation much easier.

    One question. You say, “For a “rising shed loom” (jack loom), use the white squares (or numerals) to tie up rising shafts”. Do you mean this to apply to the American way of writing the draft?

    Thank you.

    • Karen says:

      Julia, Thank you for asking this question. I need to edit what I wrote and make a correction.

      The American way of writing the draft usually has numerals for the rising shafts. For a jack loom, use the squares with numerals to tie up rising shafts. The white squares, in this case, are used to tie up sinking shafts.

      Thanks for helping me clarify!

      Karen

  • Thanks Karen, a good blog to explain the differences quite clearly. I prefer the swedish way (and yes I have a a GlimĂ„kra floor loom, but it just makes sense to me. Sometimes I get them mixed up but I think it’s good to know both methods. It’s a bit like preferring to beam the warp from the front or the back – you just tend to find what works for you. Thank you again.
    Blessings,
    Alison

    • Karen says:

      Hi Alison, I get them mixed up, too. I am so accustomed to the Swedish format that I have to go back and review my notes if I want to “translate” an American draft.

      Karen

  • Hi Karen,
    Thanks for the comparison post. It will be good to refer new weaver’s to it, so they know there is more than one way for patterns to be written.

    Here is a bit of additional information for American weaver’s used to jack loom drafts. Many own the book, A Handweaver’s Pattern Book by Marguerite Davison. It was published back when counterbalance looms were the norm. Her drafts are written in the American way, with threading and tie-up at the top. Her tie-up is written for a sinking shed, so marked boxes go down. If someone owns a jack loom, in order to see the pattern while weaving, they should tie up the blank squares instead of the x’s. I think other older drafts, such as Atwater, Bertha Hayes, and others also tie up for counterbalanced looms.

    • Karen says:

      Hi Jenny, I’m glad you mentioned this! It’s important for a weaver to understand the format of a draft and how to interpret it.

      My first project on a floor loom was from Davison’s book. My instructor carefully pointed out the author’s note that tells that the drafts are written for counterbalance looms.

      Thank you so much for adding this important information for weavers used to drafts written for jack looms.

      Karen

  • Sandy says:

    Karen, I’m new to all of this, and I’m not able to perceive what you are referring to as black and white squares. Are those the empty squares? So you would tie up all of those, vs one black thread?

    • Karen says:

      Hi Sandy, Empty or white? It’s a matter of perception. Yes, in a draft written for sinking shed looms, such as a Swedish draft, you would tie up the empty squares if you are using a jack loom. I don’t think of the squares as “empty,” because for my countermarch loom, I tie up the black squares to the shafts that sink, and I tie up those “white” squares to the shafts that rise.

      I hope that makes sense.
      Karen

  • Randi says:

    Thank you for this post. I’m a new weaver and have a counterbalance loom. I’ve ordered the book you mentioned.

    I also really enjoy your posts.

    • Karen says:

      Hi Randi, You are welcome! I wanted this kind of information when I was starting out, so I’m hoping it is useful for others. The Getzmann/Ashenden book does a great job of explaining the whole drafting concept and procedure. So does the Van der Hoogt book, for that matter. You can’t have too many weaving books! 🙂

      Happy weaving,
      Karen

  • Sandy says:

    Thank you for writing this post. I’m sure it will be very helpful to many of those seeking to expand our repertoire.

    A friend recently sent me some drafts written in the Swedish manner and, while I figured out most of it, I misinterpreted how the shafts are numbered in relation to the weaver. I’ll have to go back to my Fiberworks entry and edit it or I’ll mess up my weaving.

    I have two looms, one a computer controlled dobby that uses a programme in the American style. My other loom is a four shaft counterbalance that I brought home from Europe, so I’m somewhat used to reversing the tie-up when I weave with it. My first project ended up upside down on the loom!

    • Karen says:

      Sandy, You are going to become an expert on reading different formats of weaving drafts! Bravo! I’m guessing that just about every weaver has accidentally woven a fabric upside down. I know I have.

      The thing about reversing the order of the shafts and the treadles is that it usually doesn’t really matter all that much. As long as you are consistent, most things will come out just fine, even if they are upside down.

      Happy weaving!
      Karen

  • Sue Seymour says:

    I have learned – the hard way – to read the Intro material in any new book I purchase so as to learn which way the author is writing drafts, treadling, and tie-up. It seems there is always a new wrinkle. Even though I have a Swedish countermarche loom, I prefer the American way of drafting, which is what I learned way back when there were only three weaving books available, Mary Black, Mary Atwater, and the Davison book.

    • Karen says:

      Sue, Yes, read the intro material. It’s not unusual for you to prefer the American way of drafting. I’m sure it’s second nature for you. And those three books should still be in every weaver’s library.

      All the best,
      Karen

Leave a Reply
